Reliable network wiring for Power over Ethernet (PoE) requires the cable, RJ45 pinout, switch budget, and endpoint to work as one link. Use Cat5e or better for a channel up to 100 meters, terminate both ends with the same T568A or T568B standard, and test the wire map before connecting PoE equipment.

The correct power over ethernet cable does not create power by itself. A PoE switch or injector supplies power through the Ethernet pairs, while the powered device (PD), such as an access point, camera, or VoIP phone, negotiates the available power and draws what it needs.

Network wiring for PoE: map the link and power path

Match 802.3af, 802.3at, or 802.3bt to the endpoint’s power budget

A PoE link has four main parts: the power sourcing equipment (PSE), the permanent cable, any patch-panel or patch-cord connections, and the powered device. The PSE may be a PoE network switch or a standalone injector. Before wiring, check the endpoint datasheet for its required PoE standard and maximum wattage.

  • IEEE 802.3af, PoE: The PSE provides up to 15.4 W, with up to 12.95 W available at the PD after cable loss.
  • IEEE 802.3at, PoE+: The PSE provides up to 30 W, with up to 25.5 W available at the PD.
  • IEEE 802.3bt Type 3, PoE++: The PSE provides up to 60 W, with up to 51 W available at the PD.
  • IEEE 802.3bt Type 4: The PSE provides approximately 90 to 100 W, with up to about 71 W available at the PD.

These are maximum budgets, not guaranteed load measurements. A switch must have enough total PoE power for all connected devices at the same time. For example, a switch with a 120 W budget may support several phones but may not support four high-power cameras simultaneously. Leave capacity for startup loads and future devices.

Understand how two-pair and four-pair PoE share Ethernet pairs

Two-pair PoE uses the blue and brown pairs, with power applied over the same conductors that carry Ethernet signals. Depending on the PSE and wiring mode, power is injected through pins 1-2 and 3-6, or through pins 4-5 and 7-8. The Ethernet data remains differential, while the DC power uses common-mode transmission on each pair.

802.3af and 802.3at normally use two pairs. 802.3bt uses all four pairs to increase available power and reduce current per conductor. Gigabit Ethernet and faster Ethernet already require all four twisted pairs for data, so every pair must be correctly terminated even when the PoE standard uses only two pairs for power.

Use standards-based active PoE equipment when possible. Passive injectors can place voltage on a cable without the normal detection and classification process, so their voltage and pin assignment must match the endpoint exactly.

Choose a power over ethernet cable and route it safely

Select Cat5e, Cat6, or Cat6A for the 100-meter channel

Cat5e is the minimum practical category for standard PoE and supports Gigabit Ethernet across a 100-meter channel when properly installed. Cat6 offers more headroom for crosstalk and is a useful choice for new installations. Cat6A is preferred for 10 Gigabit Ethernet and demanding installations with long cable bundles or higher thermal loads.

The usual maximum is 100 meters total: up to 90 meters of permanent horizontal cable plus up to 10 meters of combined patch cords. Longer runs can produce excessive voltage drop, lower link performance, or unstable PoE operation. A shorter run with several poor connectors can fail even when the measured cable length is well below 100 meters.

Choose solid or stranded conductors, shielding, and a safe cable path

Use solid-conductor cable for fixed runs between a patch panel and an outlet or device location. Solid conductors have lower resistance and work with compatible keystone jacks and patch panels. Use stranded patch cable for flexible connections to the switch, patch panel, camera, or access point. Stranded cable tolerates movement but has higher resistance, so it should not replace long permanent cable.

Avoid copper-clad aluminum (CCA) cable for PoE. Its higher resistance can increase voltage drop and heat, particularly with 802.3bt power. Select cable marked for the required category and made with solid or stranded copper conductors as appropriate.

Use unshielded twisted pair (UTP) unless the installation has a clear grounding plan and a reason to control electromagnetic interference. Shielded cable, connectors, and patch-panel hardware must form a continuous, correctly bonded system; adding one shielded component to an otherwise unshielded path does not provide a complete shield.

Route the cable away from fluorescent-ballast wiring, motors, and high-voltage conductors. Follow the applicable separation and fire-rating rules, and use the jacket rating required for the location. Do not sharply bend, crush, staple, or over-tighten cable ties. High-power PoE through dense bundles can create heat, so follow the cable manufacturer’s bundle-size and temperature guidance for 802.3bt installations.

RJ45 color order: T568A or T568B, then terminate both ends

Hold the plug with contacts up, latch down, and pin 1 on the left

T568A and T568B use the same four twisted pairs but swap the green and orange pairs. Either standard works for a straight-through Ethernet and PoE cable. The essential rule is consistency: use the same standard at both ends. Mixing A at one end and B at the other creates a crossover cable, which is unnecessary for most modern switches but can cause confusion during troubleshooting.

For the specified plug orientation, hold the RJ45 plug with the gold contacts facing up, the latch facing down, and pin 1 on the left. Looking at the plug from the contact side, place the conductors from left to right in one of the following sequences.

T568A pins 1–8: white-green, green, white-orange, blue, white-blue, orange, white-brown, brown

  1. White-green
  2. Green
  3. White-orange
  4. Blue
  5. White-blue
  6. Orange
  7. White-brown
  8. Brown

T568B pins 1–8: white-orange, orange, white-green, blue, white-blue, green, white-brown, brown

  1. White-orange
  2. Orange
  3. White-green
  4. Blue
  5. White-blue
  6. Green
  7. White-brown
  8. Brown

To terminate a cable, cut the jacket cleanly and remove only enough insulation to arrange the pairs. Untwist each pair as little as possible; excessive untwisting reduces resistance to crosstalk. Arrange the eight conductors in the chosen RJ45 color order, flatten them without crossing wires, and trim their ends evenly.

Slide the conductors fully into the plug. Each conductor should reach the front of its channel, and the cable jacket should extend inside the plug so the strain-relief tab grips the jacket rather than the individual wires. Check the order again through the transparent housing, then crimp with a connector rated for the cable type and conductor size. Repeat the identical pinout at the other end.

Test continuity, wire map, link speed, and delivered PoE power

Run a continuity and wire-map test before connecting equipment

Test the finished cable before attaching a switch or endpoint. A basic cable tester should show continuity from every pin at one end to the corresponding pin at the other:

  • Pin 1 to pin 1
  • Pin 2 to pin 2
  • Pin 3 to pin 3
  • Pin 4 to pin 4
  • Pin 5 to pin 5
  • Pin 6 to pin 6
  • Pin 7 to pin 7
  • Pin 8 to pin 8

The tester should also identify opens, shorts, reversed pairs, crossed conductors, and split pairs. Continuity alone is not enough: a split pair can connect every pin and still fail because conductors from different twists have been combined. A wire-map tester or certification tester detects this fault.

If the run includes a patch panel, wall jack, coupler, or patch cord, test the complete channel rather than only the permanent cable. A correctly terminated horizontal cable can still fail because of a damaged jack or an incorrectly wired patch lead.

Confirm negotiated link speed and powered-device operation

Connect the tested run to the PoE switch and endpoint. Check the switch port’s negotiated speed and duplex status. A Gigabit link requires all four pairs; a link that falls back to 100 Mbps often indicates a damaged pair, poor termination, excessive untwisting, or a component with a lower capability. A link LED confirms some connectivity but does not prove that the cable meets its intended category or speed.

Check the switch management interface for PoE detection, classification, voltage, current, and port power. The port should identify a compatible PD and show a sensible power draw rather than repeatedly cycling between detection and shutdown. If the switch reports overload or insufficient power, compare the endpoint’s requirement with the remaining switch budget and inspect the cable length and connector quality.

Verify switch PoE status, endpoint startup, and delivered load power

The endpoint should complete its normal startup and remain stable under its expected load. For a camera, confirm that video remains available during infrared illumination or other high-load modes. For an access point, check that radios start and maintain service. For a phone, confirm that it boots and remains powered during a call.

For a final measurement, use a PoE tester or inline power meter rated for the applicable standard. Measure the delivered voltage and wattage under load at the endpoint side of the link, not only the wattage reported by the switch. The switch’s value is its output measurement and includes cable loss differently from the PD’s input measurement. A successful result is a stable data link, correct negotiated speed, recognized PoE class, and delivered power that meets the endpoint’s stated requirement.
